一、Technical performance
1. The high-end digital equipment imported chips. Volume (L×W×H):
145 ×55×45 (mm); Weight: 250 g
2. Alarm: luminous, sound, vibration triple alarm. Sound file (Ala) and vibration profile (Vib) can be arbitrary choice.
3. The use of power equipment for 6 F22-9V batteries, LED quiescent current standby <5 mA, dynamic sound and light alarm current <30 mA, vibration alarm dynamic current <60 mA. Note standby cyclical red LED lights green.
4. The equipment can work for a long time, fever, do not have been contained phenomenon. When the supply voltage less than 6 V, the following will have more than the call for sound, then power should be less than the replacement battery.
5. The high sensitivity of the equipment can detect very small iron needles decapitated, such as φ1.2 Fe test based on the block, detect a high degree of up to about 15 mm; such as iron φ0.7 * 20-pin basis for the inspection, Detection of its high degree of up to 50 mm and above.
三、Application
1. Can be knitted, clothes, socks, all wearing CLOTHING Duanzhen products for testing, can quickly find the correct wearing of clothing found in the iron-decapitated, metal-dressed to ensure their personal safety.
2. May be drugs, food, chemical raw materials such as a ferromagnetic material detection.
3. May be of wood, walls, tables Taiwan within the nails, iron bars, the presence of the pipe inspection.
4. To the human body, livestock and other work-related injuries and stab wounds, the injured and other sites for inspection, whether its internal check infiltration of harmful substances.
5, this equipment can also be used for border customs check post, the public service personnel to be seized caches of weapons to the rapid search。
