Scope of Application：
It is used for detecting broken needles in woven fabrics such as tapes. It can also detect metal impurities like broken pins, staples, blades, metal fragments, ferromagnetic metals, etc. It can also control the machine to stop.
Features：
1、Japanese technology, computer chip integrated circuits.
2、This machine has extremely high sensitivity and anti-interference performance, and can withstand long-term use. According to the specified usage, the detection effectiveness rate reaches 100%.
3、When a broken needle or a metallic object is detected, both sound and light alarms will be triggered.
4、The sensitivity can be adjusted continuously from 0 to 10.
Product Parameter： | |||
Body Material | Steel, detection surface 304 stainless steel. | ||
Size | 24.5×10×15.7CM(长×宽×高)；探测通道:14.5×3CM(宽×高) | ||
Search coverage | 145×50mm，安装孔间距271mm； | ||
Weight | 约10Kg； | Power Voltage | 交流220V |
Frequency | 50HZ； | ||
Power | 30W； | ||
Alarm method | Sound and light alarm, output shutdown signal interface. | ||
灵 敏 度Sensitivity | 铁球Fe：≥直径1.2mm；(Common broken needles and staples can be detected) | ||
验收方式 Way of checking | 一、Enterprise standard: When the randomly provided test card (with a diameter of 1.0MM for the iron ball) is moved and scanned close to the detector, it can detect and issue a sound and light alarm. If the body and appearance are intact without any defects, it is considered qualified. | ||
